BM 50 Portable Lathe (Borwerk) Machine
It is used to repair round-shaped holes in need of repair by first filling them with welding material and then applying turning process to restore them to their original dimensions.
The BM50 Portable borwerk machine reduces vibrations during operation due to its 50 mm spindle diameter. It has a wide range of applications.
It is suitable for use in machinery revision, shipyards, machine manufacturing, construction machinery such as cranes, concrete pumps, etc. It provides higher chip removal efficiency and allows the use of fewer bearing housings. It is designed to work in medium-heavy conditions.
You can perform precise welding and fast turning operations perfectly with a single machine.
The BM series machines reduce repair times by 50% due to their high speed and high torque production.
The BM series machines are twice as efficient as other machines due to their high-speed turning feature.
Precision fast servo motor control system.
2 years of electronic and mechanical warranty.
It has an adjustable chain tensioning system. Planetary reducer and servo motor are preferred in the rotation and feeding system.
The spindles used have a hardness of 62 HRC and are chrome-plated. The spindle assembly is MK4 Morse connection system.
| MODEL | MOTOR TYPE | WEIGHT KG | ROTATION SPEED | STROKE | CUTTING CAPACITY CK45 | WELDING CAPACITY |
| BM50 | AC SERVO MOTOR | 28 KG | 200 RPM/DK. | 220 mm | 52-450 mm | 58-400 |
BM50 FULL EQUIPMENT LINK
| BM50 KATALOK | GÜÇ TABLOSU | ANA YATAK ÖLÇÜLERİ | MAKİNA ÖLÇÜLERİ | BM50 EKİPMAN ÖLÇÜLERİ |
| FUNCTIONALITIES | TECHNICAL DETAILS |
| Internal Hole Turning Capacity: From 42 mm to 450 mmr |
